V-6 (Maxi. Dia 146 mm) Submersible Pumpset ( S.S. Motor Body & Pump Bowl C.I.) Suitable for 150 mm Bore Dia ( DECCAN TYPE)
(Maximum Head per Stage 35 Feet)
| Model No. | H.P. | Stage | Outlet 50 mm (2") | Discharge in L.P.M | ||||||
|---|---|---|---|---|---|---|---|---|---|---|
| 80 | 100 | 120 | 140 | 170 | 200 | 220 | ||||
| VED - 50/4 | 2.00 | 4 | Head in Meters |
32 | 30 | 27 | 24 | 20 | 13 | 10 |
| VED - 50/6 | 3.00 | 6 | 48 | 45 | 40 | 36 | 30 | 20 | 14 | |
| VED - 50/10 | 5.00 | 10 | 80 | 74 | 68 | 60 | 50 | 33 | 23 | |
Welcome to our blog
| Model No. | H.P. | Stage | Outlet 50 mm (2") | Discharge in L.P.M | ||||||
|---|---|---|---|---|---|---|---|---|---|---|
| 110 | 130 | 150 | 170 | 200 | 230 | 270 | ||||
| VED - 60/3 | 2.00 | 3 | Head in Meters |
27 | 25 | 23 | 21 | 17 | 15 | 9 |
| VED - 60/5 | 3.00 | 5 | 45 | 40 | 37 | 35 | 29 | 25 | 15 | |
| VED - 60/8 | 5.00 | 8 | 72 | 64 | 60 | 56 | 45 | 40 | 28 | |
Welcome to our blog
| Model No. | H.P. | Stage | Outlet 50 mm (2") | Discharge in L.P.M | ||||||
|---|---|---|---|---|---|---|---|---|---|---|
| 150 | 170 | 200 | 210 | 260 | 290 | 320 | ||||
| VED - 80/A | 3.00 | 4 | Head in Meters |
38 | 35 | 32 | 28 | 24 | 20 | 12 |
| VED - 80/6 | 5.00 | 6 | 57 | 53 | 48 | 42 | 36 | 30 | 18 | |
Welcome to our blog
| Model No. | H.P. | Stage | Outlet 50 mm (2") | Discharge in L.P.M | ||||||
|---|---|---|---|---|---|---|---|---|---|---|
| 150 | 170 | 200 | 210 | 260 | 290 | 320 | ||||
| VED - 100/2 | 2.00 | 2 | Head in Meters |
20 | 18 | 15 | 13 | 12 | 10 | 6 |
| VED - 100/3 | 3.00 | 3 | 30 | 27 | 23 | 20 | 18 | 15 | 9 | |
| VED - 100/5 | 5.00 | 5 | 50 | 45 | 38 | 33 | 30 | 25 | 15 | |
